Scilogex OS40-S Overhead LED Digital Stirrer, 40L, 110-220V, 50/60Hz
84020201
Sterlitech
5-7 days
Details
Scilogex OS40-S Overhead LED Digital Stirrer, 40L, 110-220V, 50/60Hz
Applications
OS20-S/OS40-S Features:
- Analog speed control with LED real-time display of speed
OS20-Pro/OS40-Pro Features:
- Anti-spill feature: PC control insures smooth acceleration, preventing spills.
- LCD real-time display: Set value and actual value are displayed.
- PC connection via RS232 Port: Allows for PC control and documentation of all measuring values.
Specifications
| OS40-Pro | OS20-Pro | OS40-S | OS20-S | |
|---|---|---|---|---|
| Maximum Stirring Quantity (Liters) | 40 L | 20 L | 40 L | 20 L |
| Motor Rating Input | 120 W | 60 W | 120 W | 60 W |
| Motor Rating Output | 100 W | 50 W | 100 W | 50 W |
| Speed Range (RPM) | 50-2200 | 50-2200 | 50-2200 | 50-2200 |
| Speed Display Accuracy | ±3% | ±3% | - | - |
| Speed Display Resolution (RPM) | 1 | 1 | 1 | 1 |
| Maximum Torque (Ncm) | 60 | 40 | 60 | 40 |
| Dimensions (mm) | 83 x 220 x 186 | 83 x 220 x 186 | 83 x 220 x 186 | 83 x 220 x 186 |
| Weight | 2.8 kg | 2.6 kg | 2.8 kg | 2.6 kg |
| Voltage (V AC) | 100-240 | 100-240 | 100-240 | 100-240 |
| Power | 130 W | 70 W | 130 W | 70 W |
| Protection Class | IP21 | IP21 | IP21 | IP21 |
| Working Temperature (C) | 5-40 | 5-40 | 5-40 | 5-40 |
