DCMD Kit with Chiller and Immersion Heater, 110V, 60Hz, 1Ph
Sterlitech’s “plug and play” DCMD test cell is a bench-scale cross/tangential flow test cell that mimics the conditions representative of a large-scale DCMD system while using minimal amounts of membrane or product.
Powered by Bioz
1200675
Sterlitech
3-4 weeks
DCMD Sepa Cell Features and Technical Specifications
| PARAMETER | DESCRIPTION |
| Membrane Operation | Forward Osmosis / Membrane Distillation |
| Cell Material | Acrylic |
| Membrane Active Area | 140 cm² (22 in²) |
| Maximum Pressure | 15.2 bar (220 PSI) |
| Maximum Temperature* | 88 °C (190 °F) |
| Recommended Feed Rate | 0.5-6 LPM (0.13-1.6 GPM) |
| Channel Dimensions | |
| Channel Depth | 1.9 mm (0.075 inches) |
| Channel Width | 95.3 mm (3.75 inches) |
| Fittings | |
| Feed Inlet/Outlet Size (Tube OD) | 3/8” Compression |
| Draw Inlet/Outlet Size (Tube OD) | 3/8” Compression |
| Securing Method | High Pressure Screws |
Note: Maximum Pressure and Temperature ratings are dependent on a variety of factors. Listed values are guidelines
based upon material properties and cannot be guaranteed in every application
