Phase/Fraction Collectors
• Collect aliquots of filtrate during the filtration process using the 2-way Y bore PTFE valve
• Prevents venting of hazardous sample or solvents to atmosphere
• Collect multiple samples with additional receiver sample tubes
• Two mounting options: P/FC 1 mounts on standard manifold or 1 L flask using a #8 stopper, P/FC 2 has female 40/35 joint to mount on an extraction manifold or 1 L flask
• Available with sintered glass, stainless steel, or PTFE support
| P/FC 1 | P/FC 2 | |
| Materials | ||
| Funnel, base unit, and receiver tube | Borosilicate glass | |
| Support | Sintered glass, stainless steel screen, or PTFE | |
| Connections | ||
| Base to outlet | #8 Stopper | 40/35 ground glass joint |
| Alternate outlet to receiver tube | Ground glass joint | |
| Capacity | ||
| Funnel | 300 mL | |
| Membrane Filter Compatibility | ||
| Membrane filter size | 47 mm | |
| Prefilter size | 35 mm | |
| Filtration area | 9.6 cm2 | |
