SCILOGEX MS-H-S10 Analog Magnetic Hotplate Stirrer 10-Channel, s/steel plate, 110V/60Hz
The MS-H-S10 10-place multiposition hotplate stirrer features a powerful rotary drive providing consistent sample conditions across each position for volumes up to 400 mL. heat only, stir only, or heat and stir simultaneously. The stirrer surface is stainless steel with a silicone anti-slip mat which is chemical resistant and easy-to-clean.
81132102
SCILOGEX
Sterlitech
Scilogex
MS-H-S10
Hotplate Stirrer (Analog)
110V/60Hz
5-7 days
Details
SCILOGEX MS-H-S10 Analog Magnetic Hotplate Stirrer 10-Channel, s/steel plate, 110V/60Hz
Specifications
Hotplate/Stirrer Performance Comparison by Manufacturer: Scilogex Stirrers | Scilogex Hotplate-Stirrers | Benchmark
Scilogex Stirrers
MS-S |
MS-PA |
MS-PB |
MS-M-S10 |
|
---|---|---|---|---|
Dimension of work plate [mm] | ø135 (5") | ø135 (5") | ø135 (5") | 180 × 450 |
Work plate material | Ceramic-coated steel | ABS Plastic | ABS Plastic | S/steel w/silicone film |
Motor type | DC brushless | DC | DC | DC brushless |
Motor rating input [W] | 18 | 5 | 5 | 12 |
Motor rating output [W] | 10 | 3 | 3 | 4 |
Power [W] | 30 | 15 | 10 | 20 |
Voltage [VAC] | 100-240 | 100-240 | 100-240 | 100-240 |
Frequency [Hz] | 50/60 | 50/60 | 50/60 | 50/60 |
Stirring positions | 1 | 1 | 1 | 10 |
Max. stirring quantity[H2O] L | 20 | 3 | 3 | 0.4 (ea. position) |
Max. magnetic bar(L × Ø) mm | 80 | 50 | 50 | 40 |
Speed Range [rpm] | 0-1500 | 100-1500 | 0-1500 | 0-1100 |
Speed display | Scale | LED | Scale | Scale |
Speed display resolution [rpm] | N/A | N/A | N/A | N/A |
Protection class [DIN EN60529] | IP42 | IP42 | IP42 | IP42 |
Dimension [W × D × H] mm | 160 × 280 × 85 | 150 × 260 × 80 | 150 × 260 × 80 | 182 × 552 × 65 |
Weight [kg] | 2.8 | 1.8 | 1.8 | 3.2 |
Max. Temperature [°C] | 340 | 280 | 280 | NA |
Permissible Relative Humidity | 80% | 80% | 80% | 80% |
Scilogex Hotplate-Stirrers:
MS7-H550-Pro |
S7-H550-S |
MS-H-Pro+ |
MS-H-S |
MS-H280-Pro |
MS-H-S10 |
|
---|---|---|---|---|---|---|
Work Plate Dim. [mm] | 184 × 184 (7") | 184 × 184 (7") | ø135 (5") | ø135 (5") | ø135 (5") | 180 × 450 |
Work plate material | Glass-ceramic | Glass-ceramic | Ceramic-coated steel | Ceramic-coated steel | Ceramic-coated steel | S/steel w/silicone film |
Motor Type | DC brushless | Shaded pole | DC brushless | DC brushless | DC | DC brushless |
Motor Rating Input [W] | 18 | 15 | 18 | 18 | 5 | 12 |
Motor Rating Output [W] | 10 | 1.5 | 10 | 10 | 3 | 4 |
Power [W] | 1050 | 1030 | 550 | 530 | 515 | 490 |
Voltage [VAC] | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 |
Frequency [Hz] | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Stirring Positions | 1 | 1 | 1 | 1 | 1 | 10 |
Max. Stirring Quantity[H2O] L | 20 | 10 | 20 | 20 | 3 | 0.4 (ea. position) |
Max. Magnetic Bar(L × Ø) mm | 80 | 80 | 80 | 80 | 50 | 40 |
Speed Range [rpm] | 100-1500 | 0-1500 | 100-1500 | 0-1500 | 100-1500 | 0-1100 |
Speed Display | LCD | Scale | LCD | Scale | LED | Scale |
Speed Display Resolution [rpm] | +-1 | N/A | +-1 | N/A | N/A | N/A |
Protection Class (DIN EN60529) | IP21 | IP21 | IP42 | IP42 | IP21 | IP42 |
Dimensions [W × D × H] mm | 215 × 360 × 112 | 215 × 360 × 112 | 160 × 280 × 85 | 160 × 280 × 85 | 150 × 260 × 80 | 182 × 552 × 65 |
Weight [kg] | 5.3 | 4.5 | 2.8 | 1.8 | 1.8 | 3.2 |
Max. Temperature [°C] | 550 | 550 | 340 | 340 | 280 | NA |
Permissible Relative Humidity | 80% | 80% | 80% | 80% | 80% | 80% |
Heating output [W] | 1,000 | 1,000 | 500 | 500 | 500 | 470 |
Safety Temp. [°C] | 580 | 580 | 360 | 350 | 320 | 140 |
Temp. Display | LCD | LED | LCD | Scale | LED | Scale |
Benchmark Stirrers, Hotplates, and Hotplate-Stirrers:
H4000 Stirrer |
H4000 Hotplate |
H4000 Hotplate-Stirrer |
|
---|---|---|---|
Work Plate Dim. [mm] | 7.5 × 7.5" | 7.5 × 7.5" | 7.5 × 7.5" |
Work Plate Material | Ceramic | Ceramic | Ceramic |
Voltage [VAC] | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 |
Frequency [Hz] | 50/60 | 50/60 | 50/60 |
Stirring Positions | 1 | N/A | 1 |
Speed Range [rpm] | 60-1500 | N/A | 60-1500 |
Speed Display | Analog | N/A | Analog |
Dimensions [W × D × H] | 8 × 9 × 4.5" | 8 × 9 × 4.5" | 8 × 9 × 4.5" |
Ambient Temp. Range [°C] | +5-380 | +5-380 | +5-380 |
Control | Quick Adjustment Knob | Quick Adjustment Knob | Quick Adjustment Knob |
