SKU: 313200
Stainless Steel Vacuum Sterility Test Manifold, 6-Position, Standard Cup, 3-Way Valve, KM6
$5,719.20
Key Specifications
- Material Type
- Stainless Steel
- Valve
- 3-Way
- Brand
- Advantec
Features
- Autoclavable
- 2-way or 3-way valve available, use a 3-way valve when the manifold is used under closed conditions and must be vented to atmosphere without breaking the vacuum connection. 3-way valve vent is female luer slip, accepts standard disposable syringe filter or stainless steel syringe filter holder (KS 13)
- Standard cup accepts a #8 stopper to adapt microanalysis units and other devices
- Exterior taper accepts a 40/35 female joint
- Sterility Test Manifold features rear mounted flushing manifold for use in USP bacteria retentive method
Advantec Vacuum Manifold Specification
| Specification | Single | 3-Station | 6-Station |
|---|---|---|---|
| Materials | |||
| Body and branches | Type 304 stainless steel | Type 304 stainless steel | Type 304 stainless steel |
| Valves | PTFE stopcock, chrome plated brass body | PTFE stopcock, chrome plated brass body | PTFE stopcock, chrome plated brass body |
| Connections | |||
| Outlet | 1/4" male NPT to hose barb fitting connects main manifold to 3/8" ID vacuum tubing | 1/4" male NPT to hose barb fitting connects main manifold to 3/8" ID vacuum tubing | 1/4" male NPT to hose barb fitting connects main manifold to 3/8" ID vacuum tubing |
| Standard cup | Accepts #8 and #8b stopper | Accepts #8 and #8b stopper | Accepts #8 and #8b stopper |
| Dimensions | 8 x 4 3/4 x 8" | 18 x 4 3/4 x 7" | 28 1/2 x 4 3/4 x 7" |
| Distance between stations (center to center) | N/A | 5 1/2" | 4 3/4" |
| Weight | 5.5 lb | 9.9 lb | 14.3 lb |
