Underdrain support (316 SS), KST 47 (47mm), Filter Holder with Reservoir
Details
Underdrain support (316 SS), KST 47 (47mm), Filter Holder with Reservoir
Applications
- In-line gas or liquid filtration
- Ultraclean or sterilize gas or liquids
- Flow decay tests for pilot studies
- Hazardous toxicity testing and TCLP
Specifications
|
KS 90 |
KS 142 |
KS 293 |
KS 90 UH |
KS 142 UH |
KS 293 UH |
KST 47 |
KST 90 |
KST 142 |
---|---|---|---|---|---|---|---|---|---|
Filter size (mm) |
90 |
142 |
293 |
90 |
142 |
293 |
47 |
90 |
142 |
Body |
304 or 316 stainless steel |
304 or 316 stainless steel |
304 or 316 stainless steel |
304 stainless steel |
304 stainless steel |
304 stainless steel |
304 SS |
304 or 316 stainless steel |
304 or 316 stainless steel |
O-ring & Gasket |
Silicone and PTFE |
Silicone and PTFE |
Silicone and PTFE |
Silicone |
Silicone |
Silicone |
Silicone and PTFE |
Silicone and PTFE |
Silicone and PTFE |
Inlet/Outlet |
¾” NPTF and NPTM to 3/8” hose barb (ST Models: 1.5" Sanitary fitting to 14.3 mm hose barb) |
¾” NPTF and NPTM to 3/8” hose barb (ST Models: 1.5" Sanitary fitting to 14.3 mm hose barb) |
¾” NPTF and NPTM to 5/8” hose barb |
¾” NPTF and NPTM with 11 mm hose barb adapter |
¾” NPTF and NPTM with 11 mm hose barb adapter |
¾” NPTF and NPTM with 16 mm hose barb adapter |
¼” NPTM with 11 mm hose barb adapter |
¼” NPTM w/ ball valve stepped
|
¼” NPTM w/ ball valve stepped
|
Max Pressure Inlet (psi) |
99 |
99 |
99 |
99 |
99 |
99 |
71 |
71 |
71 |
Max Pressure Diff. (psi) |
<42 |
<42 |
<42 |
<42 |
<42 |
<42 |
<42 |
<42 |
<42 |
Filtration Area (cm2) |
45.3 |
113 |
530 |
45.3 |
113 |
530 |
12.5 |
43 |
113 |
