HP4750 Stirred Cell

HP4750 Stirred Cell
The Sterlitech HP4750 stirred cell is a high-pressure stirred cell that is both chemically resistant and features a low hold-up volume (1 ml). This particular brand of stirred cell is able to perform a wide variety of membrane separations.

HP4750 Stirred Cell Product Benefits:
  • Max operating pressure is 1000 psi
  • Removable PTFE stir bar
  • 316 stainless steel
Click here to go back to Stirred Cells
Principles of Operation (image will open in new window)
SKU Name Price
HP4750 HP4750 Stirred Cell up to 1000 psig
$2,476.30

1144026 Pressure Regulator (N2, He, Ar), CGA 580, 1000 psig
$885.58

1155893 Pressure Relief Bleed Valve, 1000 psig
$243.96

1151427 High Pressure Hose, 6ft, 3000 psi rated
$88.00

1144030 Magnetic Stirring Plate 115 VA 60 Hz
$216.20

1144031 Magnetic Stirring Plate 220 VA 50 Hz
$216.20

1144035-110 Mechanical Stirrer with 316 Stainless Stir Bar and Shaft (110V)
$5,503.37

16056DIN10B54 Pressure Regulator Conversion Kit, DIN 10 Assembly, 1/4" NPTM
$224.73

1144035-230 Mechanical Stirrer with 316 Stainless Stir Bar and Shaft (230V)
$5,503.37

Safe Operation: Volatile solutions can be processed safely because the Sterlitech™ HP4750 operates on standard sources of compressed air or inert gases (nitrogen, argon, etc.). This provides the user with a variable, safe and consistent supply of pressure to effect membrane separations.

High-Pressure Operation: Solutions with high levels of dissolved solids and high osmotic pressure can be separated with the Sterlitech™ HP4750. The cell is designed for safe operation to 1000 psig (69 bar).

Removable Stir Bar: Concentration polarization at the membrane surface is minimized by a PTFE-coated magnetic stir bar mechanism. The stir bar can be driven by any standard stirring plate.

Accepts Standard Membrane Discs: Sterlitech™ HP4750 Stirred Cell accommodates any 47 to 50 mm diameter membrane disc.

Chemically Resistant Materials of Construction: 316L stainless steel construction makes the Sterlitech™ HP4750 resistant to most chemical degradation. Buna-N gaskets and O-rings are provided as standard with other optional materials available to meet operating requirements.

Unique Design: The cell top can easily be removed to fill the vessel with up to 300 mL of solution. The cell bottom is removable for quick membrane change-out. The top and bottom are secured to the vessel with mechanical couplings. This unique design enables low hold-up volume, down to as low as 1 mL, so valuable solutions are not wasted.

Membrane Size 1.93 inch diameter nominal (49 mm)
Active Membrane Area 2.26 inch2 (14.6 cm2)
Processing Volume Up to 300 mL
Hold-Up Volume 1 mL
Maximum Pressure 1000 psig (69 bar) with high-pressure clamps
Maximum Temperature 250 °F (121 °C) at 800 psig (55 bar)
pH Range Membrane dependent
Connections Permeate Outlet: 0.125 dia. 316L SS tubing ; Pressure Inlet: ¼ inch FNPT
Cell Body 316L stainless steel
O-Rings Buna-N, others available as options
Gasket Buna-N, others available as options.
Stir Bar PTFE
Cell Diameter 2.0 inch (5.1 cm)
Cell Height 7.8 inch (19.9 cm)
Cell Width with high-pressure couplings 5.7 inch (14.6 cm)

What size membrane does the HP4750 Stirred Cell use?

Q. What size membrane does the HP4750 Stirred Cell use?

A. Any 47-50mm membrane disc can be used.

What material is the HP4750 Stirred Cell made out of?

Q. What material is the HP4750 Stirred Cell made out of?

A. The cell itself is constructed of 316 stainless steel and utilizes a PTFE coated stirrer for chemical resistance.

What type of stir plate do you recommend for use with the HP4750 Stirred Cell?

Q. What type of stir plate do you recommend for use with the HP4750 Stirred Cell?

A. Any conventional magnetic stirrer will work.

What do I do to release the pressure on the HP4750 Stirred Cell?

Q. What do I do to release the pressure on the HP4750 Stirred Cell?

A. You will need a tee that has a needle valve so that you can slowly release the pressure when ready to lower the pressure. You will need a needle valve rated for at least 1000 psi with a ¼' NPT.

Can I cut a membrane for use in the HP4750?

Q. Can I cut a membrane for use in the HP4750?

A. Yes, use the metal membrane support as a guide for cutting a disc.
