Gast Vacuum Pump
The Gast vacuum pump maintains a continuous vacuum for filtration and can also be used as a positive pressure filtration pump (<60 psi).
Gast Vacuum Filtration Pump Product Benefits:
- Oil-free operation minimizes aerosol contamination
- Quiet operation
- Easy to maintain
- Portable, compact design
| Specification | Description |
|---|---|
| Wetted parts | Aluminum, stainless steel, and Nordell Normax |
| Valves | Reed type |
| Power cord | 6' long, 3-wire |
| Horse power | 1/8 HP |
| Inlet and outlet ports | 1/4" NPTF to hose barb fitting connects vacuum pump to 3/8" ID vacuum tubing |
| Power requirements | 115 V AC/60 Hz or 220 V AC/50 Hz |
| Maximum pressure | 60 psi |
| Maximum vacuum | 25" Hg |
| Maximum inlet | 100°F (37.8°C) |
| Free Air Capacity | 1.2 cfm (34 L/min) |
| Weight | 20 lb (9.1kg) |
