Magnetic Stirrers & Hotplates

Sterlitech’s assortment of Biomega hotplates and stirrers are feature an exceptionally durable, chemical-resistant white ceramic work surface. The space saving design of the H4000-HS hotplate and magnetic stirrer, the H4000-S magnetic stirrer and the H4000-H hotplate, (8” x 9” footprint) makes them ideal for use on crowded bench tops and inside of bio-hoods.

Magnetic Stirrer & Hotplates Brochure

Products
Application

SKU	Name	Price

H4000-S115	Magnetic Stirrer, 115 V, 60 Hz	$209.90	0 in cart
H4000-S230	Magnetic Stirrer, 230V, 50Hz	$209.90	0 in cart
H4000-H115	Hotplate, 115 V, 60 Hz	$209.90	0 in cart
H4000-H230	Hotplate, 230V, 50Hz	$209.90	0 in cart
H4000-HS115	Hotplate & Stirrer, 115 V, 60 Hz	$319.90	0 in cart
H4000-HS230	Hotplate & Stirrer, 230V, 50Hz	$319.90	0 in cart
H4000-ROD	Stainless Steel Rod, 12" (30 cm)	$15.90	0 in cart
81322300	SCILOGEX MS7-H550-Pro Magnetic Hotplate & Stirrer, 110V/60Hz	$575.00	0 in cart
81322100	SCILOGEX MS7-H550-S Magnetic Hotplate & Stirrer, 110V/60Hz	$460.00	0 in cart
81321300	SCILOGEX MS7-Pro Magnetic Hotplate & Stirrer, 110V/60Hz	$465.00	0 in cart
81321100	SCILOGEX MS7-S Magnetic Hotplate & Stirrer, 110V/60Hz	$410.00	0 in cart
81111104	SCILOGEX MS-S Magnetic Stirrer, steel plate, 110V/60Hz	$265.00	0 in cart
81111112	SCILOGEX MS-S Magnetic Stirrer, porcelain plate, 110V/60Hz	$255.00	0 in cart
81111302	SCILOGEX MS-Pro Magnetic Stirrer, steel plate, 110V/60Hz	$395.00	0 in cart
81111315	SCILOGEX MS-Pro Magnetic Stirrer, porcelain plate, 110V/60Hz	$405.00	0 in cart
81112104	SCILOGEX MS-H-S Magnetic Hotplate & Stirrer, steel plate, 110V/60Hz	$315.00	0 in cart
81112102	SCILOGEX MS-H-S Magnetic Hotplate & Stirrer, porcelain plate, 110V/60Hz	$315.00	0 in cart
81112304	SCILOGEX MS-H-Pro Magnetic Hotplate & Stirrer, steel plate, 110V/60Hz	$455.00	0 in cart
81112302	SCILOGEX MS-H-Pro Magnetic Hotplate & Stirrer, porcelain plate, 110V/60Hz	$455.00	0 in cart
81131102	SCILOGEX MS-M-S10 Magnetic Stirrer, steel plate, 110V/60Hz	$992.00	0 in cart
81132102	SCILOGEX MS-H-S10 Magnetic Hotplate & Stirrer, steel plate, 110V/60Hz	$1,550.00	0 in cart
18900001	Carrying plate for quarter pie reaction blocks	$102.48	0 in cart
18900065	Containment ring to secure quarter pie reaction blocks in hotplate	$102.48	0 in cart
18900002	Red quarter reaction block, 15.2mm x 20mm	$71.98	0 in cart
18900003	Purple quarter reaction block, 28mm x 24mm	$58.56	0 in cart
18900004	Blue quarter reaction block, 28mm x 30mm	$63.44	0 in cart
18900005	Black quarter reaction block, 28mm x 43mm	$69.54	0 in cart
18900048	Green quarter reaction block, 17.75mm x 26mm	$69.54	0 in cart
18900049	Gold quarter reaction block, 21.6mm x 31.7mm	$64.66	0 in cart
18900080	Reaction block for 50ml round bottom flasks	$119.00	0 in cart
18900081	Reaction block for 1000ml round bottom flasks	$124.00	0 in cart
18900082	Reaction block for 250ml round bottom flasks	$136.00	0 in cart
18900083	Reaction block for 500ml round bottom flasks	$143.00	0 in cart
D-101100	SCILOGEX PTFE Magnetic Stirring Bar, 10 x 3mm	$6.20	0 in cart
D-101150	SCILOGEX PTFE Magnetic Stirring Bar, 13 x 8mm	$6.33	0 in cart
D-101200	SCILOGEX PTFE Magnetic Stirring Bar, 19 x 8mm	$6.58	0 in cart
D-101250	SCILOGEX PTFE Magnetic Stirring Bar, with pivot ring, 25 x 7.9mm	$6.47	0 in cart
D-101300	SCILOGEX PTFE Magnetic Stirring Bar, with pivot ring, 32 x 7.9mm	$8.58	0 in cart
D-101400	SCILOGEX PTFE Magnetic Stirring Bar, with pivot ring, 38 x 9.5mm	$11.52	0 in cart
D-101500	SCILOGEX PTFE Magnetic Stirring Bar, with pivot ring, 51 x 9.5mm	$14.33	0 in cart
D-101650	SCILOGEX PTFE Magnetic Stirring Bar, with pivot ring, 75 x 12mm	$16.65	0 in cart
D-110000	SCILOGEX PTFE Stirring Bar Remover	$19.13	0 in cart
18900016	SCILOGEX PT 1000 Temperature sensor	$125.00	0 in cart
18900017	SCILOGEX PT1000 Sensor support rod & clamp	$58.50	0 in cart

Advanced microprocessor controls with convenient turn knobs allow quick, precise adjustment and maintenance of speed and temperature. Safety indicator LED's on the front panel indicate when the heating and/or stirring functions have been activated.

With a square 7.5 in work surface, all three models are compatible with a wide variety of popular sizes of borosilicate glass beakers, flasks, bottles and other vessels. The hotplate/magnetic stirrer model (H4000-HS) comes complete with a support rod for mounting thermometers and temperature probes.

Technical Data - Magnetic Stirrer (H4000-S)

Speed Range:	60 - 1500 rpm
Platform:	7.5 x 7.5in / 19 x 19cm
Control:	Quick Adjustment Knob
Dimensions:	8 (W) x 9 (D) x 4.5 (H) in
Electrical Data:	120V, 60Hz / 230V, 50/60 Hz*

Technical Data - Hotplate (H4000-H)

Temperature Range:	Ambient +5 to 380ºC
Platform:	7.5 x 7.5 in / 19 x 19cm
Control:	Quick Adjustment Knob
Dimensions:	8 (W) x 9 (D) x 4.5 (H) in
Electrical Data:	120V, 60Hz / 230V, 50/60 Hz*

Technical Data - Hotplate/Magnetic Stirrer (H4000-HS)

Speed Range:	60 - 1500 rpm
Temperature Range:	Ambient +5 to 380ºC
Platform:	7.5 x 7.5 in / 19 x 19cm
Control:	Quick Adjustment Knob
Dimensions:	8 (W) x 9 (D) x 4.5 (H) in
Electrical Data:	120V, 60Hz / 230V, 50/60 Hz*

Watch a video of the Biomega Magnetic Stirrer
