Disposable Ultrafiltration Unit, 50K MWCO

Additional Information

SKU	UFDIS5024
Price	$154.25
Name	Disposable Ultrafiltration Unit, 50K MWCO
Pack Size	24

Email to a Friend

Qty:

Disposable Ultrafiltration Unit, 50K MWCO

More Views

Details
Application
Product & Performance

Return to all Ultrafiltration (UF) Columns

Disposable and reusable ultrafiltration (UF) columns from Sterlitech can easily concentrate, separate, or purify samples in the ultrafiltration range using positive pressure. The disposable units are available in 10K, 50K and 200K cut-offs. They also feature a clear filtration chamber to visually monitor the filtration process.

Our reusable unit performs a similar function using a centrifuge method and a 13 mm filter diameter to easily collect the concentrated sample solution, the filtrate, or both (13 mm filter sold separately). Consult our Flat Sheet Membrane section to select the corresponding membrabe for your application.

Disposable UF Columns Guide
Reusable UF Columns Guide

Filtration of small volume samples (<2 ml)

Specification	Description
Disposable UF Column Specifications:

Effective Filtration Area	2.0 cm2
Maximum Cell Capacity	2.0 ml
Minimum Graduated Volume	0.5 ml
Minimum Recovery Volume	0.2 ml
Maximum Concentration	X40
Maximum Temp	50 C
Maximum Pressure	0.29 Mpa (42.6 PSI)
Filtrate Cell Capacity	2.5 ml
Sterilization	25% Ethanol, 5% Formalin

Reusable UF Holder Specifications:

Filter Diameter	13 mm
Effective Filtration Area	0.65 cm2
Minimum Sample Volume	0.15 ml
Maximum Sample Volume	2.0 ml
Maximum Centrifugal Force	19,600 m/s2
Total Liquid Volume	0.01 ml
