Ultrafiltration (UF) Columns

Disposable and reusable ultrafiltration (UF) columns from Sterlitech can easily concentrate, separate, or purify samples in the ultrafiltration range using positive pressure. The disposable units are available in 10K, 50K and 200K cut-offs. They also feature a clear filtration chamber to visually monitor the filtration process.

Our reusable unit performs a similar function using a centrifuge method and a 13 mm filter diameter to easily collect the concentrated sample solution, the filtrate, or both (13 mm filter sold separately). Consult our UF Flat Sheet Membrane section to select the corresponding membrane for your application.

Disposable UF Columns Guide
Reusable UF Columns Guide

Products
Application
Product & Performance

4 Item(s)

Show per page

Sort By

SKU	Name	Pack Size	Price
UFDIS1024	Disposable Ultrafiltration Unit, 10K MWCO	24	$154.25
UFDIS5024	Disposable Ultrafiltration Unit, 50K MWCO	24	$154.25
UFDIS20024	Disposable Ultrafiltration Unit, 200K MWCO	24	$154.25
UFREU1301	Reusable Ultrafiltration Holder, 13mm	1	$338.60

4 Item(s)

Show per page

Sort By

Filtration of small volume samples (<2 ml)

Specification	Description
Disposable Spin Column Specifications:

Effective Filtration Area	2.0 cm2
Maximum Cell Capacity	2.0 ml
Minimum Graduated Volume	0.5 ml
Minimum Recovery Volume	0.2 ml
Maximum Concentration	X40
Maximum Temp	50 C
Maximum Pressure	0.29 Mpa (42.6 PSI)
Filtrate Cell Capacity	2.5 ml
Sterilization	25% Ethanol, 5% Formalin

Reusable Spin Column Specifications:

Filter Diameter	13 mm
Effective Filtration Area	0.65 cm2
Minimum Sample Volume	0.15 ml
Maximum Sample Volume	2.0 ml
Maximum Centrifugal Force	19,600 m/s2
Total Liquid Volume	0.01 ml
