Stainless Steel Syringe Holders

Use Sterlitech stainless steel syringe holders when filtering or cleaning small volumes of liquid. SS syringe filter holders are also useful when clarifying turbid solutions and purifying virus solutions.

Stainless Steel Syringe Filter Holder Product Benefits:

Made with 304 stainless steel
Autoclavable
Luer fittings
Wrench set included for easy tightening

Click here to go back to Syringe Holders
Click here for replacement parts for this product

Products
Application
Product & Performance

SKU	Name	Price

301000	13 mm Syringe	$98.33	0 in cart
301200	25 mm Syringe	$164.18	0 in cart

Filter or Clean small volumes of liquid
Clarify turbid solutions
Purify virus solutions

Specification	Description
Body, Support Screen	304 Stainless Steel
O-rings	PTFE
Inlet Connection	Female Luer-lock
Outlet Connection	Male Luer slip
Pressure Inlet	99 psi (0.68 MPa)
Pressure Differential	42 psi (0.29 MPa)
Gasket	PTFE
Dead Volume: Upstream/Downstream	13 mm: 0.2 ml; 25 ml: 0.4 ml
Membrane Filter Size	13 mm: 13 mm; 25 mm: 25 mm
Prefilter Size	13 mm: 8 mm; 25 mm: 21 mm
Filtration Area	13 mm: 0.9 cm²; 25 mm: 3.8 cm²
Diameter	13 mm: 0.6" (16 mm); 25 mm: 1.25" (32 mm)
Weight	13 mm: 0.25 lbs (0.1 kg); 25 mm: 0.38 lbs (0.2 kg)
