Rocker 440 Air Compressor

The Sterlitech Rocker 440 air compressor for the Rocker Series of vacuum filtration pumps consists of a compressor, a stainless steel air tank and a pressure regulator/moisture trap. The Rocker 440 system pumps air into the tank which then flows through the pressure regulator/moisture trap. After regulating and filtrating, the air then travels to the attached device.

Click here to go back to Pressure Filtration Pumps

Rocker 440 Air Compressor Technical Data

Products
Application
Product & Performance

SKU	Power Requirements	Price

167440-11	115V/60 Hz	$1,012.73	0 in cart
167440-22	220V/50 Hz	$1,012.73	0 in cart

Quiet and low vibration
- Driven directly by motor without transmitted mechanism; high quality construction keeps the noise level only at 50dB, which is one of the lowest among equivalent products.
Clean and maintenance free
- The Rocker 440 is next to maintenance-free because of the oil-free design. The Rocker 440 comes with guaranteed operation of two-years or 3000 working hours of free service parts (excluding the moisture filter).

Specification	Description
Horsepower	1/6 HP
Motor Speed	1700 rpm (110v) ; 1400 rpm (220v)
Power Requirements	115 V AC/60 Hz or 220 V AC/50 Hz
Max Pressure	60 psi
Pressure (0 psi)	27 lpm (110v) ; 25 lpm (220v)
Pressure (20 psi)	23 lpm (110v) ; 23 lpm (220v)
Pressure (30 psi)	22 lpm (110v) ; 18 lpm (220v)
Pressure (40 psi)	20 lpm (110v) ; 16 lpm (220v)
Weight	20.7 lbs (9.4 kg)
Noise	50 dB
