Pressure Filtration Vessels
Our pressure filtration vessels can be used with vacuum or pressure filtration. All Sterlitech stainless steel pressure filtration vessels include a pressure gauge, safety relief valve, ball valve, elbows, hose barb connectors (3/8" OD tubing) and a dip tube. The opening is an oval top, 4 7/8" x 5 7/8" (12.4 x 14.9 cm). See the accompanying picture for reference.
Click here to go back to Large Filter Holders
Click here to go back to Pressure Vessels
Click here for replacement parts for this product
- Contain process fluids for filtration through pressure type membrane filter holders.
- Type 316/316L stainless complies with current good manufacturing practices and are recommended for low pH and high salt applications.
- Includes pressure gauge, safety relief valve, hose barb connectors (3/8" OD tubing), dip tube
- 9" Inside Diameter
Note: Cells are not autoclavable.
Pressure Vessel Performance and Dimension Data
| Maximum Operating Temperature | Pressures | ||
| ºF | ºC | psi | Bar |
| 100 | 38 | 165 | 11.4 |
| 200 | 93 | 165 | 11.4 |
| 300 | 149 | 155 | 10.7 |
** Maximum operating temperature and pressure may be limited by vent relief valve maximum pressure, O-ring maximum temperature, rubber skirt maximum temperature, or other factors.
Pressure Vessel Dimensions
| Volume | Dimensions | ||
| Gallons | Liters | Inside Dimensions | Height |
| 1 | 3.8 | 9" (23 cm) | 9.25" (23.5 cm) |
| 3 | 11.36 | 9" (23 cm) | 15" (38 cm) |
| 5 | 18.93 | 9" (23 cm) | 22.25" (56.5 cm) |
| Specification | Description |
|---|---|
| Body, Support Screen | Type 316L stainless steel |
| O-rings | EPDM |
| Inlet Connection | 1/4" NPTF |
| Outlet Connection | 1/4" NPTF |
| Maximum Temperature | See Table in Applications Tab |
| Autoclave | Cells are not autoclavable. |
| Diameter | See Pressure Vessel Performance and Dimension Data |
| Height | See Pressure Vessel Performance and Dimension Data |
| Weight | See Pressure Vessel Performance and Dimension Data |
