Lg Standard Stainless Steel Holders, Lg Sanitary Stainless Steel Holders, Parts

Lg Standard Stainless Steel Holders, Lg Sanitary Stainless Steel Holders, Parts

Sterlitech carries an assortment of parts for Large Stainless Steel Holders and Large Sanitary Stainless Steel Holders. Options include: inlet adapters, vent relief, inlet plates, outlet adapters, flow deflectors, O-rings, gaskets, legs and leg washers, sealing wing nuts, underdrain supports and more.

Click on the “Applications” tab below for more detailed information on the various large stainless steel filter holder pressure filtration parts and supplies we sell.

Click here to go to Large Stainless Steel Filter Holders
Click here to go to Large Sanitary Stainless Steel Holders.

SKU Number Size (mm) Description Price
300913 1 90, 142 Inlet adapter (316 SS)
$170.07

300917 21 142 Outlet adapter, 3/4" NPTF to 3/8" Barb
$170.07

301703 11 90 Gasket (PTFE)
$147.11

301705 9 90 O-ring (silicone)
$25.40

301706 9 90 O-ring (FEP-encapsulated silicone)
$43.95

301707 9 90 O-ring (FPM), 2/pk
$56.95

301718 15 90, 142 Sealing bolt (leg)
$22.42

301726 90 Back pressure support screen (304 SS)
$308.45

301727 90 Back pressure support screen (PTFE coated 304 SS)
$474.55

301802 12 90 Underdrain support (316 SS)
$265.95

301804 10a 90 Support screen (PTFE coated SS)
$616.91

301808 4 Flow deflector (316 SS)
$86.58

301901 13 142 Outlet plate (304 SS), 3/4" NPTF
$1,091.45

301903 11 142 Gasket (PTFE)
$332.18

301905 9 142 O-ring (silicone)
$34.29

301906 9 142 O-ring (FEP-encapsulated silicone)
$26.02

301907 9 142 O-ring (FPM)
$50.27

301909 3 142 Inlet plate (304 SS)
$491.42

301915 18 90, 142 Wing-type bolt
$71.18

301922 Spanner (wrench), 142 mm
$71.18

301926 142 Back pressure support screen (304 SS)
$642.22

301927 142 Back pressure support screen (PTFE coated 304 SS)
$301.55

301928 142 Back pressure support screen (316 SS)
$759.27

301929 142 Back pressure support screen (PTFE coated 316 SS
$917.44

302002 12 142 Underdrain support (316 SS)
$371.05

302004 10a 142 Support screen (PTFE coated SS)
$1,091.45

302009 3 142 Inlet plate (316 SS)
$510.22

302035 8 142 Support screen (316 SS)
$901.64

302208 90, 142 Flow deflector (316 SS)
$92.78

302209 142 Inlet plate (316 SS)
$612.62

302503 7 293 Gasket (PTFE)
$735.55

302505 5 293 O-ring (silicone)
$59.56

302506 7 293 O-ring (FEP-encapsulated silicone)
$61.20

302507 7 293 O-ring (Viton)
$213.55

302514 14 293 Sealing wing nut
$99.65

302518 12 293 Leg washer
$13.76

302531 293 Back pressure support screen (PTFE coated 304SS)
$425.25

302533 293 Back pressure support screen (PTFE coated 316SS)
$425.25

302602 8 293 Underdrain support (316 SS)
$1,144.11

302604 6 293 Support screen (PTFE coated SS)
$1,613.45

302635 8 293 Support screen (316 SS)
$1,376.18

302808 293 Flow deflector (316 SS)
$108.24

306000 3 47 Clamp, 1.5TC (304SS)
$85.42

306108 2 47 Inlet cap gasket/O-ring (silicone)
$5.40

306109 2 47 Inlet cap gasket (PTFE)
$14.75

306110 2 47 Inlet cap gasket (FPM)
$14.49

306204 Inlet, Outlet adapter (316 SS)
$306.13

Replacement Parts

 Inlet and Outlet Assemblies
    KS 90 KS 142 KS 293
1  Inlet adapter (304 SS)
 300813   302513
1  Inlet adapter (316 SS)
  300913   302613
2  Vent relief valve (40 psi)
  301825
3  Inlet plate (304 SS)
  300809  301909  302509
3  Inlet plate (316 SS)
  300909  302009  302609
9  Outlet plate (304 SS)
 300801  301901  302501
9  Outlet plate (316 SS)
  300901  302001  302604
10  Outlet adapter (304 SS)
  300817   302517
10  Outlet adapter 316 SS)
  300917   302617
Filter Support System
    KS 90 KS 142 KS 293
4  Flow deflector (316 SS) 301808
5  O-ring (silicone) 301705 301905 302505
6  Support screen (PTFE coated SS) 301804 302004 302604
7  Gasket (PTFE) 301703 301903 302503
8  Underdrain support (316 SS) 301802 302002 302602
Sealing and Support Assemblies
    KS 90 KS 142 KS 293
11  Leg 301709 301919 302519
12  Leg washer  -  301720  302518
13  Leg bolt  301718  -
14  Sealing wing nut  301914   302514
15  Sealing washer  901916   302516
16  Sealing bolt  301915   302515



Accessories

    KS 90 KS 142 KS 293
7  O-ring (FEP-encapsulated silicone)  301706 301906
 302506
7  O-ring (Viton)
 301707  301907 302507
8  Support screen (316 SS)
  301835  302035  302635
-  Back pressure support screen (304 SS)
  301726  301926  302530
-  Back pressure support screen (316 SS)  301728  301928  302532
-  Back pressure support screen (PTFE coated 304 SS)  301727  301927  302531
   Back pressure support screen (PTFE coated 316 SS)  301729  301929  302533
   Allen wrench (hex key) 6mm  301721   -
 Spanner (wrench) 142mm  301922
